Features

For maximum thermal protection, choose Raynor's TH160, our durable, energy-efficient sectional garage door. Our exclusive process fills 100% of the door's interior space with energy-saving polyurethane foam insulation to deliver exceptional R-values. This process also provides superior foam density for excellent structural integrity. With standard features like the corrosive resistant rigid aluminum retainer and the EPDM rubber floor seal, the TH160 is built to last!
Contact us about this product
DOWNLOAD PRODUCT BROCHURE
Door
Type   Commercial Sectional Garage Doors
Model   TH160
Size   24' x 22' Max
Operation   Manual, Motor or Hand Chain
IECC Thermal Performance   N/A
Sections
Construction   3-Layer Sandwich
Material   Steel
Surface Texture   Stucco Exterior, Stucco Interior
Section Joint   Ship Lap
Section Thickness   1-5/8"
Gauge   Exterior Steel Thickness 0.015"
Stiles   16-Gauge
Insulation   Polyurethane (R-value = 14.86)
Seals   Thermal Break, Bottom Seal (3")
Trussing   Wind Load: 20 P.S.F. Tested/13.3 P.S.F. Design Load (standard); Material: U-bar 4", 6", or 8" sizes
Panel Configuration   NA
Color   White
Windows   24"x12" two piece acrylic, clear insulated glass, clear insulated tempered
Track
Type   Normal Headroom, Rear Mount Low Headroom, Front Mount Low Headroom, Lift Clearance, Vertical Lift, Incline, Contour
Finish   Galvanized
Size   2" or 3"
Gauge   12, 13, 16-gauge
Counterbalance System
Type   Torsion Spring, Tandem Shaft Torsion Spring, or Weight Counter-Balance
Springs   Spring Inner Diameter: 2-1/4", 3-1/2" or 5-1/2"; Duplex or High Cycle (30K, 50K, 100K)
Shafts   Tube (13 gauge) or Solid (D-Shaft, 1" Keyed, 1-1/4" Keyed)
Hardware/Accessories
Hinges   11, 13, 14-Gauge or Hybrid
Rollers   Standard (2" or 3") or Heavy Duty (2" or 3")
Finish   Galvanized
Lock   Interior Slide Lock
Seal   Header Seal or Jamb Seal
Hanger Angle   11, 13, 16-Gauge
Pedestrian Door   NA
Optional Wind Loading   Certified Wind Load Available
Posts   NA
Limited Warranty *
Section Warranty   10-Year Rust-Through and Delamination
Hardware Warranty   1-Year
Spring Warranty   1-Year



TH160 garage doors are available in White.

Specifications Word Document PDF document
Raynor Quick Spec Microsoft Word Document PDF Document
CSI Master Format Microsoft Word Document PDF Document



Track Selection Guide
Normal Headroom
Normal Headroom
Lift Clearance
Lift Clearance
Low Headroom (Front Mount)
Low Headroom (Front Mount)
Low Headroom (Rear Mount)
Low Headroom (Rear Mount)
Vertical Lift
Vertical Lift
Incline
Incline
Contour
Vertical Lift A-Type




Section and Panel Schedules
 Garage Door Width  Number of Raised Panels    Garage Door Height  Number of Sections
5' 3" - 9' 2" 2 Up to 8' 2" 4
9' 3" - 12' 2" 3 8' 3" - 10' 2" 5
12' 3" - 16' 2" 4 10' 3" - 12' 2" 6
16' 3" - 20' 2" 5 12' 3" - 14' 2" 7
24' 3" - 28' 2" 7 16' 3" - 18' 2" 9
20' 3" - 24' 2" 6 14' 3" - 16' 2" 8
    18' 3" - 20' 2" 10



TH160 Warranty

Door Sections
Raynor warrants the door sections against defects in material and workmanship, and deterioration due to rust-through for ten (10) years from date of delivery to the original purchaser. Raynor also warrants the door sections against delamination of the polyurethane foam insulation from the steel skins for ten (10) years from date of delivery to the original purchaser. Window components are warranted against defects in material and workmanship for one (1) year from date of delivery to the original purchaser.

Hardware & Spring Components
Raynor warrants all hardware and spring components against defects in material and workmanship for one (1) year.

OPTIFINISH™ (post paint)

Raynor warrants the OptiFinish (exterior only) against cracking or peeling (losing adhesion) for one (1) year from date of delivery to the original purchaser. Cracking or peeling caused by dents or scratches is not covered. Fading is not covered by this warranty.

WARRANTY LIMITATIONS and EXCLUSIONS

Under the terms of this limited warranty, for any door components that are found to be defective upon inspection by authorized Raynor personnel, Raynor will, at its option, repair or replace the defective door components. Labor charges for the installation or repairs shall be the responsibility of the consumer and must be performed by an authorized Raynor dealer.

This warranty extends only to the original purchaser, provided the door is installed in his/her place of business. This warranty is not transferable.

This warranty does not apply to any damage or deterioration to the door caused by abuse, negligence, missing components, accidents, use of pressure washers, dents or scratches. Shavings from trolley rails not properly removed and cleaned from the exterior door surface causing rust are not covered by this warranty. Failure to provide proper maintenance voids this warranty. Field applied paint failure is not covered by this warranty. Refer to the Care and Maintenance Instructions and Painting Instructions.

This warranty does not apply to damage caused by fire, an act of God, accident, vandalism or graffiti. Damage or deterioration caused by saltwater coastal areas (within two miles), hazardous or corrosive chemicals and fumes including, but not limited to, alkaline, acids, muriatic acids, road salt or salt environments, harsh cleaning agents, and fertilizers is not covered by this warranty.

Raynor shall not be liable for any consequential or incidental damages.

ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANT OF MERCHANTABILITY, ARE HEREBY EXPRESSLY EXCLUDED.

Some states do not allow the exclusion or limitation of consequential or incidental damages, so the above limitation or exclusion may not apply to you.

Claims for defects in material and workmanship covered by this warranty shall be made in writing with proof of purchase and photographs of the product in question to the dealer from whom the product was purchased or call Raynor at 1-800-4-RAYNOR within the warranty period. Raynor may choose to have the product returned for inspection.

This warranty gives you specific legal rights. You may also have other rights, which may vary from state to state.
