Thermomark™ 530

Premium 3” Thick Polyurethane Insulated Door Delivers Optimum Return on Investment

ThermoMark™ Model 530 is the strongest and most thermally efficient door in the Wayne Dalton product line-up. Premium 3” thick foamed-in-place polyurethane insulation provides one of the most thermally efficient doors in the industry.
Contact us about this product
DOWNLOAD PRODUCT BROCHURE

ThermoMark™ Model 530 is designed to withstand tough weather conditions and is the preferred choice for large openings where thermal performance and durability are essential.

Wayne Dalton’s ThermoMark™ insulated doors help to minimize energy costs and provide year-round comfort and security for your building. Inside and outside skins are roll-formed and separated with a 1-3/4” true PVC thermal break to eliminate heat or cold transfer from front to back steel skins. Hot-dipped galvanized steel and rugged construction will give years of solid performance for the most demanding conditions.

Key Product Features

  • Max Width: 40’2”
  • Max Height: 24’1”
  • 27-gauge exterior steel
  • Polyurethane insulation
  • 3” section thickness
  • 10,000 cycle standard spring
  • Continuous steel strips for hinge attachment
  • Patented dual barrier tongue-and-groove joint profile
  • PVC thermal break – prevents heat/cold transfer on end stiles

* Wayne Dalton uses a calculated door section R-value for insulated doors.
† with jamb seal

Thermal Efficiency Values

  • R-value* = 26
  • U-factor = .038
  • Installed U-factor = .14
  • Air leakage rating = .09†
  • STC (sound transmission rating) = 22

Door Construction

foamed-in-place polyurethane sections

3” thick foamed-in-place polyurethane sections feature continuous steel strips for flexibility in hinge placement.


Joint profile

Patented dual barrier tongue-and-groove joint profile creates a virtually impenetrable path for air leakage in between sections.


Jamb seal

Patented thermal performance jamb seal (optional) combines a longer flapper seal and bulb seal for superior perimeter protection.


Weatherseal

Bottom weather seal with rigid PVC retainer and dual durometer PCV bulb seal locks out air and water leakage through the bottom section. Optional outer EPDM bulb seal provides additional protection.


thermal break

PVC thermal break on end stiles limits the transfer of temperature.

IECC® Compliant

The ThermoMark™ 530 meets IECC® requirements for maximum U-factor of operable fenestrations (2015 Section C402.4) with a 3rd party certified tested value of less than 0.37. ThermoMark™ 530 also meets the ASHRAE 90.1 and IECC® requirement for maximum air leakage for fenestration assemblies (2015 Section C402.5.2 Garage doors) with a 3rd party certified tested value of less than 0.40.

Lite Options

Multiwall Polycarbonate Lites

Large lites (24" w x 13" h) available with insulated glass, tempered glass, or multi-wall polycarbonate glazing (brown, white or clear). Black frame is standard. Color matched frames are available.

Options & Accessories

  • Chain hoist operation
  • Motor Operation
  • Sensing edges
  • Photo eyes
  • Cable failure device
  • High cycle springs (25k, 50k, 100k)
  • Special track designs
  • High usage components
  • Patented advanced thermal performance clip-on jamb seal

Wind Safe logo

*Static (Non-Impact) Wind Load designs are based on engineering analysis and although not certified by FBC, TDI, or Miami-Dade, the designs are compliant with the 2015 IBC.



Color Options

Online color swatches are only digital reproductions of actual standards and will vary in appearance due to differences in monitor and video card output. These digital representations should not be used to finalize color selection(s).
