GRAND HARBOR® collection

Steel and composite carriage house garage doors with or without insulation.

When budget is the deciding factor, this low-maintenance, insulation-optional steel frame carriage house style garage door combines clean lines and classic charm to provide a popular style at a great value.
Contact us about this product
DOWNLOAD PRODUCT BROCHURE

by :
Clopay Garage Doors

Overview

A great choice for both new construction or  a low-maintenance replacement, the GRAND HARBOR® collection of garage doors is a versatile carriage house design that complements a wide range of architectural styles.

Construction Overview

  • Smooth composite overlays are adhered to a flush 24-gauge steel door, with 2- or 1-layer carriage house construction.
  • Optional 1-5/8" vinyl-backed polystyrene insulation improves energy efficiency. Insulated doors have a 6.3 R-value.
  • The steel skins of these doors are protected by the use of a tough, layered coating system, which includes a hot-dipped galvanized layer and baked-on primer and top coat.
  • WINDCODE® reinforcement product available for high wind load applications.

Design Overview

  • Four factory finish paint colors.
  • Clear, obscure, and acrylic glass options available.
  • Attractive beveled edge clip-in window grilles are removable for easy cleaning.
  • Garage doors come complete with spade lift handles and step plates. Additional decorative hardware options available.

Calculated door section R-value is in accordance with DASMA TDS-163.


Paint Limited Life Warranty10 year window and overlay warranty5 year warranty overlay delamanation3 year limited hardware warranty



Lift Master Elite Series LIFTMASTER® ELITE SERIES™
Clopay recommends the LiftMaster® Elite Series opener for these garage doors.

Door Designs

SERIES 1

DESIGN11
DESIGN12
DESIGN13

SERIES 2

DESIGN21
DESIGN22

SERIES 3

DESIGN31
DESIGN36

SERIES 4

DESIGN41
For more information regarding construction options per panel style, click here

Top Sections

SOLID TOP SECTIONS - SERIES 1 & SERIES 2

TOP11
TOP12
TOP13
ARCH1

SOLID TOP SECTIONS - SERIES 3 & SERIES 4

TOP11
ARCH1

WINDOW DESIGNS

PLAIN SHORT
SQ22 - GH
PLAIN LONG
REC12
REC14
SQ24
ARCH1
GRVA1
GRLA1
XA24*
XG14*
XG24*
WROUGHT IRON SHORT
WROUGHT IRON LONG

DOUBLE TOP SECTIONS

ARCH3 - SOLID (Double Door)
ARCH3 - WINDOW (Double Door)
GRLA3 - WINDOW (Double Door)
GRVA3 - WINDOW (DOUBLE DOOR)
XA314 - WINDOW (DOUBLE DOOR)
XA324 - WINDOW (DOUBLE DOOR)
*Faux windows.

Colors

STANDARD WHITE
ALMOND
DESERT TAN
SANDTONE

*Available on select models. For more information regarding color availability, click here.
Color Blast Custom Paint Option Available.

Hardware Designs

CLAVOS

DIAMOND CLAVOS
ROUND CLAVOS

HANDLES

SPADE LIFT HANDLES
(standard)
ESCUTCHEON PLATE(S)
TWISTED "T" HANDLE

HINGES

SPADE STRAP HINGE

PLATES

SPADE STEP PLATE
(standard)
  1. Smooth composite overlay
  2. Steel
  3. 1 5/8" polystyrene insulation (optional)
  • Replaceable vinyl bottom weather seal in rust free aluminum retainer helps protect against the elements.
  • Grilles are removable for easy cleaning.
  • Patented Safe-T-Bracket® - Prevents serious injury that could occur if the bottom bracket were removed with the garage door closed and under tension.
  • Rust-Prevention System - Steel skins are protected through a tough, layered coating system, including a hot-dipped galvanized layer, a protective metal oxide pretreatment and a baked on primer and top coat.

Safe-T Bracket  Paint System Rust Prevention
       Safe T-Bracket®          Rust-Prevention System

Door sample is shown in white.

Grand Harbor construction
